Thetford N4170 3 Way Absorption Caravan Motorhome Fridge Freezer

Thetford N4170 3 Way Absorption Caravan Motorhome Fridge Freezer

The Thetford N4170 Caravan and Motorhome Fridge Freezer is a quiet running and powerful 3 way, absorption fridge with a large 167 litre gross capacity making it ideal for campervans, motorhomes or caravans.

A lockable door means that the Thetford N4170 Caravan and Motorhome fridge freezer will stay securely shut whilst your vehicle is in transit, while adjustable door bins, shelving and a bottle slide will keep your goods from moving about or coming loose within the fridge.

For ease of use the Thetford N4170 3 way fridge freezer features an electric ignition and is available in a choice of automatic or manual power source selection.

Please note: The Thetford N4170 3 Way Absorption Caravan and Motorhome Fridge Freezer is now supplied with a reversible hinge as standard and as such can be installed as either a left or right handed hinge, and replaces the N3170

Thetford LED (E+) control panel:

Thetford E model fridges, which were once manual, have now been replaced with the E+ range, which are automatic, making all of the fridges in the N4000 series fully automatic. The E+ models keep things simple with a sleek and clear LED display.

Thetford LCD (A) control panel:

The A model fridges are also fully automatic, and features an advanced LCD control panel for easier diagnostics and control.



Thetford N4170 3 Way Absorption Caravan and Motorhome Fridge Freezer Features:

• Compact design
• Automatic or manual power source selection available
• Securely closed door
• Flexible bottle slide
• 3 flexible white door bins and shelves
• Flat framed 10mm door
• LCD Control panel
• Power cables and gas inlet tube at the bottom-backside of the fridge
• First class cooling performance
• Quiet to run
• 3-year guarantee
• CE mark of quality, CFC-free and almost entirely recyclable
• Please ensure you have measured the fridge correctly before purchasing, re-stock fees can apply if a fridge has been opened.
• All gas appliances must be fitted by a qualified gas engineer, failure to do so can affect your warranty..
• Please ensure you have measured the fridge correctly before purchasing, re-stock fees can apply if a fridge has been opened.

Thetford had some production/supply issues with fridge shelves towards the end of last year and rather than withhold entire production of the fridges, they issued a number of them without. You should find a note in the fridge explaining how to order them FOC directly to you.

User Manual:

Installation Manual:



/* Style Definitions */
table.MsoNormalTable
{mso-style-name:”Table Normal”;
mso-tstyle-rowband-size:0;
mso-tstyle-colband-size:0;
mso-style-noshow:yes;
mso-style-parent:””;
mso-padding-alt:0cm 5.4pt 0cm 5.4pt;
mso-para-margin:0cm;
mso-para-margin-bottom:.0001pt;
mso-pagination:widow-orphan;
font-size:10.0pt;
font-family:”Times New Roman”;
mso-ansi-language:#0400;
mso-fareast-language:#0400;
mso-bidi-language:#0400;}

Technical Specifications:

Height (mm):

1245

Width (mm):

525

Depth (mm):

593

Operation:

Absorption

Total Volume:

167 Litres

Freezer Volume:

29 Litres

Wheel Arch Model:

No

Door Hinge:

Left

Usable Power Source:

AC / DC / Gas

Power Source Selection:

Automatic

Control Panel:

LCD

Energy Consumption:

4.0 kWh/24h

Energy Consumption Gas:

420 g/24h

Net Weight:

39.0 Kg
